Cambridge CXN V2 – Streamer di rete Hi Fi

DAC: Dual Wolfson WM8740 24-bit DACs

Analogue Filter: 2-Pole Dual Differential Bessel Double Virtual, Earth Balanced

THD:
@ 1kHz 0dBFs <0.001% 24-bit (at volume set to full)
@ 1kHz -10dBFs <0.001% (at volume set to full)
@ 20kHz 0dBFs <0.002% (at volume set to full)

Frequency response: 20Hz-20kHz +/- 0.1dB

S/N ratio: -112dBr (at volume set to full)

Total Correlated Jitter: < 130pS

Crosstalk:
@ 1kHz < -100dB
@ 20kHz < -90dB

Digital Outputs:
S/PDIF Coaxial: 16/24-bit, 32-192kHz
TOSLINK Optical: 16/24-bit, 32-96kHz

Audio Formats: WAV containing uncompressed, PCM 16-24 bit 32-192kHz, FLAC containing losslessly compressed, PCM 16-24 bit 32-192kHz, Apple Lossless (ALAC) containing losslessly compressed PCM 16-24 bit 32-192kHz, AIFF containing uncompressed, PCM 16-24 bit 32-192kHz, Microsoft® Windows Media TM Audio (WMA 9 Standard) 32-320kbps, MP3 (CBR or VBR) 16-320kbps, AAC, HE AAC and AAC+, (CBR or VBR) 16-320kbps, OGG Vorbis 32-320kbps

Streaming protocols: RTSP (Real Time Streaming Protocol), MMS (Microsoft Media Server Protocol), HTTP (Hyper Text Transfer Protocol).

Connectivity: UPnP, Local USB media, Airplay 2, Chromecast built-in, Internet Radio, Spotify Connect, TIDAL, Qobuz, Roon Ready.

Playlist: ASX (Microsoft® playlist format) M3U, PLS

WiFi: IEEE 802.11 b/g or n (2.4GHz only)

Ethernet: IEEE 802.3, 10 Base-T or 100 Base-T

USB: 3 x USB 1.1 current limited to 1A each

File System: FAT32, NTFS

Standby Consumption: <0.5W

Max Power Consumption: 30W

Dimensions (HxWxD): 85 x 430 x 305 mm

Weight: 4kg

User Manual CXN V2: Download
